Description
| Type of vessel: | Bulkcarrier | ||
| Builder (where built) / Yard number: | JAPAN MARINE UNITED CORPORATION YOKOHAMA SHIPYARD | 5085 | |
| Date delivered (built): | 2017 | ||
| Classification society: | Nippon Kaiji Kyokai | ||
| Date and place of last dry dock: | Not Applicable | ||
| Date next dry dock is due: | Jun 29, 2020 | ||
| Date of last annual survey / next survey due: | Apr 25, 2020 | Jun 29, 2022 | |
| Length Over All (LOA): | 198 Metres | ||
| Length Between Perpendiculars (LBP): | 195 Metres | ||
| Extreme breadth (Beam): | 32.26 Metres | ||
| Moulded depth: | 18.60 Metres | ||
| Keel to Masthead (KTM) / KTM in collapsed condition (if applicable): | 46.55 Metres | Metres | |
| Gross Tonnage (GT) / Net Registered Tonnage (NRT): | 34.323 | 19.691 | |
| Loadline | Deadweight | Draft | TPC |
| Summer: | 60238 Metric Tonnes | 12.936 Metres | 60.24 Metric Tonnes |
| Lightship: | 0 Metric Tonnes | 2.280 Metres | 51.40 Metric Tonnes |
| Number of holds: | 5 | ||
| Total: | 77239.9 Cu. Metres | 72354.6 Cu. Metres | |
| Tanktop strength: | Hold #1, #2, #3, #4, #5: 26.5 MT/sqm Hold #6, #7, #8, #9: 0 MT/sqm | ||
| Type of hold paint: | EPOXY | ||
| Number of hatches: | 5 | ||
| Make and type of hatch covers: | IKNOW MACHINERY / FOLDING | ||
| Hatch dimensions: | Hatch #1: #1=L:17.6 B:17.1 Hatch #10, #11, #12, #13, #14, #15, #16, #17, #18, #19, #20, #6, #7, #8, #9: 0 Hatch #2: #2-L:20.8 B:18.6 Hatch #3: #3-L:20.8 B:18.6 Hatch #4: #4-L:20.8 B:18.6 Hatch #5: #5-L:20.8 B:18.6 | ||
| State deck strength: | 3.50 MT/sqm | ||
| Capacity of ballast tanks (100%): | 17655.57 Cu. Metres | ||
| If geared state make and type: | IHI DECK CRANE-MARK II 30 T | ||
| Number/location of derricks/cranes: | 4 x 30 Metric Tonnes CL 1-2 CH/CL 2-3 CH/CL 3-4 CH/CL 4-5 CH | ||
| Engine make/model and type: | WARTSILA 6RT-FLEX50-D TYPE MARINE DIESEL ENGINE / TYPE MARINE DIESEL ENGINE | ||
| BHP / RPM of main engine at MCR: | 100 % | 11224 bhp | 99.0 rpm |
| BHP / RPM of main engine at NCR (as % of MCR): | 72.5 % | 8140 bhp | 88.9 rpm |
| What type/viscosity of fuel is used for main propulsion: | RMG 380 | ||
| Capacity of main engine bunker tanks: | 1715.62 Cu. Metres | ||
| What type/viscosity of fuel is used in the generating plant: | RMG 380 | ||
| Capacity of aux engine(s) bunker tanks: | 368.84 Cu. Metres | ||
| Ballast: | 14 Knots (WSNP) | ||
| Laden: | 14 Knots (WSNP) |
